Core Bore Drill CB744 18″ – 25AMP|1PH – Rig-Mounted
$1,805.05
Core Bore Drill CB744 18″ – 25AMP|1PH – Rig-Mounted has a verified model conflict: manufacturer and retailer sources identify part 4244128 as the Core Bore CB515 hand-held core drill, not a CB744 rig-mounted drill. Use the verified CB515 configuration for import review: Power: 1800 W / 115 V / 15 AMP, Voltage/source: 115V, Capacity: 6" mounted / 3" hand-held; some retailer listings describe 5" bit capacity, Speed: 2-speed, 1400 / 2300 RPM, Mount: Hand-Held.
Core Bore Drill CB744 18″ – 25AMP|1PH – Rig-Mounted should be reviewed before storefront import because the store title and verified manufacturer data do not agree. Equipment Broker Group's title references CB744, while Diamond Products and retailer sources match part number 4244128 to the Core Bore CB515 hand-held electric core drill. The enrichment therefore keeps the store title intact, flags the conflict, and uses the traceable CB515 specifications for the part number. Verified buying details include Power: 1800 W / 115 V / 15 AMP, Voltage/source: 115V, Capacity: 6" mounted / 3" hand-held; some retailer listings describe 5" bit capacity, Speed: 2-speed, 1400 / 2300 RPM, Mount: Hand-Held. The tool is best treated as a compact hand-held core drill for smaller wet cores and stand-assisted light coring, not as an 18 in CB744 rig motor unless the SKU/title is corrected. Included items are recorded as: CB515 drill motor, plastic molded carrying case, side handle, 5/8-11 adapter, and wrench per Diamond Products source. Confirm the intended model with the supplier before publishing or importing updated specs.
Key Features
- 1800 W / 115 V / 15 AMP power configuration matched to the verified product source
- 115V power/drive requirement captured for jobsite planning
- 6" mounted / 3" hand-held; some retailer listings describe 5" bit capacity drilling or boring capacity for selecting the right bit and setup
- 2-speed, 1400 / 2300 RPM speed range or gearbox detail supports bit-size control
- 5/8"-11 spindle/thread detail helps confirm bit and adapter compatibility
- Hand-Held mount/system configuration supports correct rig pairing
- Hand-held format supports fast setup for smaller penetrations and repair work
- Wet/dry or water connection details help crews plan slurry and dust control
Specifications
- Amperage: 15 AMP
- Max Bit Diameter: 6" mounted / 3" hand-held; some retailer listings describe 5" bit capacity
- Power Phase: 1PH
- Power Source: Electric
- Recommended Bit Diameter: 3" (Hand-Held) / 6" (Mounted)
- Tool Mount: Hand-Held
- Wet/Dry Use: Wet
- Available Variants: 1 Phase – 115V 1 Phase – 230V
- Manufacturer: Core Bore
- Model #: CB515
- SKU/Part #: 4244128
- Product Type: Core Drill
- Product Subtype: Hand-Held
- Product Mount: Hand-Held
- Engine/Motor: Electric Motor
- Horse Power: ~2.4 HP (1800W)
- Voltage: 115V
- Variable Speed: 2-Speed
- Speed 1 Max RPM: 1400 RPM
- Speed 2 Max RPM: 2300 RPM
- Max Speed RPM: 2300 RPM
- Drilling Depth per Pass: User-Dependent
- Spindle Features: 5/8"-11
- Dust Collection System: Not applicable
- Weight (lbs): 10.5
- Clutch: Slip
- Leveling Bubbles: Bull's Eye Level
- Thermal Protection: Overload and Overheat Protection
- Compact Design: Yes
- Applications: Concrete, Masonry, Stone
- Dry/Wet: Wet
- Power Compatibility: Standard Electric Supply
- Product Warranty: 1 Year
- WooCommerce SKU: 4244128
- Store Title: Core Bore Drill CB744 18″ – 25AMP
- 1PH – Rig-Mounted
- Collection: Core Drilling
- Brand: Core Bore
- Verified Manufacturer Model: Core Bore CB515
- SKU Match Status: UNVERIFIED title conflict – Equipment Broker Group title says CB744 18 in 25 AMP rig-mounted, but manufacturer and retailers identify part 4244128 as CB515 hand-held motor
- Manufacturer Part Number: 4244128
- Catalog Number: 98794
- Power: 1800 W / 115 V / 15 AMP
- Speed: 2-speed, 1400 / 2300 RPM
- Weight: 10.5 lb
- Included: CB515 drill motor, plastic molded carrying case, side handle, 5/8-11 adapter, and wrench per Diamond Products source
