Generator 16kW | Honda | 240V USA-Spec

Makinex Generator 16kW Generator is a generator designed for portable or standby jobsite power for tools, lighting, and equipment. The Generator 16kW configuration pairs 16 kW output class, 120V single phase; 240V three phase voltage, and 60 Hz frequency.

Key differentiators

• Compact 240V three-phase generator for contractors who need power near the work.
• Honda GX690 engine supports serviceability and jobsite reliability.
• Runs single-phase and three-phase outlets from one portable package.
• 342 lb dry weight and small footprint help fit trailers and tight locations.
• Permanent magnet alternator technology reduces size and ownership complexity.
• 9 gal tank and 0.92 gal/hr half-load fuel economy are captured for run planning.

Specifications

Store SKU

GPE211035

Manufacturer Product Code

GEN-16P-US-240-V2

Equipment Type

Portable dual-phase gasoline generator

Output Class

16 kW

Voltage

120V single phase; 240V three phase

Frequency

60 Hz

Three-Phase Power

Max 16.8 kW / continuous 15 kW

Three-Phase Current

Max 40 A / continuous 36 A

Single-Phase Current

Max 23 A / continuous 20 A

Engine Type

Twin-cylinder air-cooled petrol

Engine Model

Honda GX690

Displacement

688 cc

Starting System

Electric key start

Fuel Economy

0.92 gal/hr at 50% load

Fuel Tank

9.0 gal

Noise Level

72 dB no-load at 7 m

Dry Weight

342 lb

Dimensions

30.4 x 20.8 x 35.5 in

Warranty

1-year warranty listed by Makinex

Best-fit applications

The Generator 16kW is best matched to portable or standby jobsite power for tools, lighting, and equipment where the job requires 16 kW output class, 120V single phase; 240V three phase voltage, and 60 Hz frequency.

• Site utility or fuel: 120V single phase; 240V three phase
• Confirm delivery ZIP code and carrier-accessible receiving details before checkout
