Challenger 44040 Heavy-Duty 4-Post Lift 40,000 lb – New Black Color

Product Overview

Challenger 44040 Heavy-Duty 4-Post Truck Lift 40,000 lb Capacity – New Black Color

The Challenger 44040 is engineered for the most demanding heavy-duty lifting applications in commercial truck and fleet service environments. With a 40,000 lb lifting capacity, this industrial-grade four-post lift is built to handle large axle vehicles including waste trucks, commercial delivery vehicles, transit buses, and heavy construction equipment. Featuring Challenger's exclusive variable-synchro power system with dual hydraulic cylinders, this lift provides the unique ability to raise and lower the front or rear suspension independently or simultaneously—a critical advantage when working with vehicles that have significantly heavier front or rear axles.

Built with heavy-duty high tensile strength leaf chain and sealed roller bearings, the 44040 delivers maximum reliability shift after shift. The velocity fused redundant hydraulic safety system and single point air actuated lock release ensure technician safety and operational efficiency. Now available in a sleek new black finish, this lift combines professional aesthetics with industrial-strength performance. Available in three length configurations standard ( 44040 ), extended ( 44040E ), and extra long ( 44040X )—to accommodate wheelbases from 310 inches to 430 inches.

Engineered for Heavy-Duty Commercial Applications

The Challenger 44040 represents the pinnacle of four-post lift engineering for heavy commercial applications. Unlike standard lifts, this system features a variable-synchro power system with dual heavy duty lift cylinders and lever controls that provide variable or synchronous power to the front and/or rear suspension. This advanced design is perfect for lifting vehicles with uneven weight distribution—waste trucks with heavy compaction equipment in the rear, dump trucks with loaded beds, or delivery trucks with concentrated cargo weight.

The lift's 10HP motor drives the system through heavy-duty high tensile strength leaf chain, delivering smooth, reliable operation with a rise time of just 70 seconds to the full 73-inch rise height. The sealed roller bearings ensure maximum reliability with minimal maintenance, while the velocity fused redundant hydraulic safety system provides multiple layers of protection for both the vehicle and technician.

Independent Control Console for Safe Operation

Safety and convenience meet in the independent control console, mounted away from the hydraulic lift for optimal technician positioning. This comprehensive control center features the variable-synchro power system controls that allow you to raise and lower the front or rear suspension either simultaneously or independently—critical when working with vehicles that have unbalanced weight distribution.

Dual pressure gauges provide real-time monitoring of hydraulic pressure at both the front and rear cylinders, ensuring balanced lifting and alerting operators to any system irregularities. The single point air lock release button allows the technician to disengage all column locks simultaneously with compressed air, eliminating the need to manually release each lock position individually—a significant time-saver that also keeps technicians safely away from the lifting mechanism during lock release.

Diamond Plate Anti-Skid Runways and Heavy Duty Approach Ramps

Vehicle traction and operator confidence start at the approach. The 44040 features heavy-duty fixed approach ramps with diamond plate anti-skid surfaces that are securely bolted down for safe and easy drive-on access. The diamond plate texture provides positive traction even with wet tires or in humid shop conditions, while the fixed bolt-down design eliminates any shift or movement during vehicle loading.

The runways are fully adjustable to accommodate a variety of tread widths and axle configurations, with a width between runways ranging from 36 inches to 58 inches. Each runway measures 32 inches wide and sits at a 14-inch height, providing a stable, low-profile platform. The 17-foot 1-1/4-inch overall width and 144-inch inside column spacing ensure compatibility with everything from standard commercial trucks to wide-body transit vehicles.

Ten-Level Twin Ladder Lock Positions

Versatility is built into every inch of the 44040's 73-inch rise height. The 10-level twin ladder lock positions provide precise height adjustment to create the ideal working height for any service task—from underneath brake and suspension work at lower heights to transmission service and exhaust system repairs at mid-height positions, all the way to full-rise cab and body work.

Each lock position is engaged automatically as the lift rises, and the single point air actuated release system allows for simultaneous disengagement of all locks with the push of a button. This dual-column lock design provides redundant safety and rock-solid stability at every height, even when working with the maximum 40,000 lb capacity.

Built-In Runway Rail System for Shop Efficiency

The 44040 includes a built-in runway rail system designed to accept optional convenience accessories such as rolling jacks and sliding oil drain pans. This integrated rail system keeps essential tools within easy reach and allows technicians to position jacks and service equipment exactly where needed along the full length of the vehicle—no more dragging heavy equipment across the shop floor or struggling with positioning.

Combined with the lift's adjustable runway width, this feature transforms the 44040 into a complete service platform that streamlines workflow and reduces technician fatigue. The long-lasting durability of the diamond plate runways ensures this rail system will continue to function smoothly for decades of heavy use.

Three Length Configurations for Any Wheelbase

Whether you're servicing standard commercial trucks or extended-wheelbase specialty vehicles, the Challenger 44040 series offers the perfect fit:

• Model 44040 (Standard): 36-foot overall length, accommodates wheelbases up to 310 inches

• Model 44040E (Extended): 41-foot overall length, accommodates wheelbases up to 370 inches

• Model 44040X (Extra Long): 46-foot overall length, accommodates wheelbases up to 430 inches

All three models share the same 40,000 lb capacity, 17-foot 1-1/4-inch overall width, and 73-inch rise height, ensuring consistent performance regardless of length. The 92-inch overall height fits comfortably in most commercial service facilities with standard ceiling clearance.

Key Advantages at a Glance

• 40,000 lb lifting capacity handles the heaviest commercial trucks, transit vehicles, and construction equipment

• Variable-synchro power system with dual hydraulic cylinders for independent or simultaneous front/rear lifting—ideal for vehicles with unbalanced weight distribution

• Velocity fused redundant hydraulic safety system and 10-level twin ladder locks provide multiple layers of safety protection

• Single point air actuated lock release allows technician to disengage all column locks simultaneously for fast, safe operation

• Heavy-duty high tensile strength leaf chain and sealed roller bearings ensure decades of reliable, low-maintenance service

Watch the Challenger 44040 in Action

Product Features

• 40,000 lifting capacity for heavy commercial truck and transit vehicles

• Heavy duty, high tensile strength leaf chain and sealed roller bearings for maximum reliability

• Variable-synchro power system with dual hydraulic lift cylinders provide the ability to variably or simultaneously raise the front or rear lift suspension, providing a stable platform when lifting vehicles with heavier front or rear axles

• Velocity fused redundant hydraulic safety system

• Single point air actuated lock release system allows technician to disengage all column locks simultaneously

• Diamond plate anti-skid runways and heavy duty fixed approach ramps for positive vehicle traction and long lasting durability

• Adjustable runways accommodate a variety of tread and axle widths

• Built-in runway rail system for optional convenience accessories like rolling jacks and sliding oil drain pan

Product Specifications

Model Number

44040
44040E
44040X

Lift Capacity

40,000 lbs.

A Overall Length

36'

41'

46'

B Overall Width

17' 1-1/4"

C Inside Columns

144"

D Between Columns

290"

350"

410"

E Overall Height

92"

F Height of Runways

14"

G Width of Runways

32"

H Width Between Runways

36" – 58"

I Maximum Wheelbase

310"

370"

430"

J Rise Height

73"

Motor

10HP

Voltage 3 Phase

230v – 460v

Speed of Rise

70 seconds

Amps

30

Shipping Weight

12050 lbs.
(5466 kg)

13050 lbs.
(5919 kg)

14525 lbs.
(6588 kg)

Available in Black Only

Key Features

• Published product configuration: Challenger 44040 Heavy-Duty 4-Post Truck Lift 40,000 lb Capacity – New Black Color The Challenger 44040 is engineered for the most demanding heavy-duty lifting applications in commercial truck and fleet service environments. With a 40,000 lb lifting capacity, this industrial-grade four-post lift is built to handle
• Exact manufacturer model or part number: 44040
• Cataloged for Lifts & Hoists: Car Lifts — 4 Post Lifts – Heavy-Duty
• 2 product manual or technical documents linked below
• Condition: New

Product Specifications

Before You Order

Confirm that model 44040, the listed capacity or working range, power requirements, dimensions, and site-delivery needs match your application. Only specifications stated in this listing should be used for purchase planning.

Manuals & Technical Resources

• Manufacturer document 1
• Manufacturer document 2
